Foundation Plans: include drawings for a standard, daylight or partial basement, crawlspace, pier, or slab foundation. All necessary notations and dimensions are included. (Foundation options will vary for each plan. If the home you want does not have the type of foundation you desire, contact us to discuss having that plan created.)
Detailed Floor Plans: show the placement of interior walls and the dimensions for rooms, doors, windows, stairways, etc., of each level of the house. In some cases, the door and window dimensions and/or stair details may be on a separate page.
Exterior Elevations: show the front, rear and sides of the house, including exterior materials, details and measurements.
Wall Sections and/or Cross Sections: show details of the house as though it were cut in slices from the roof to the foundation. The cross sections specify the home's construction, insulation, flooring and roofing details.
Roof Details: show slope, pitch and location of dormers, gables and other roof elements, including clerestory windows and skylights. These details may be shown on the elevation sheet or on a s eparate diagram. Note: If trusses are used, we suggest using a local truss manufacturer to design your trusses to comply with your local codes and regulations.
Standard Construction Details: various details related to beam support, floor construction, connections, and roofing options.
The following may also be included:
Interior Elevations: show the specific details of cabinets (kitchen, bathroom, and utility room), fireplaces, built-in units, and other special interior features, depending on the nature and complexity of the item. Note: To save money and to accommodate your own style and taste, we suggest contacting local cabinet and fireplace distributors for sizes and styles.
Schematic Electrical Layouts: show the suggested locations for switches, fixtures and outlets. These details may be shown on the floor plan or on a separate diagram.
Want to make changes?
Receive a FREE modification estimate in one of 3 ways. Our modification team is ready to help you adjust any plan to fit your needs. The ReDesign process is simple and estimates are free!
QUICK Cost-To-Build estimates have the following assumptions:
QUICK Cost-To-Build estimates are available for single family, stick-built, detached, 1 story, 1.5 story and 2 story home plans with attached or detached garages, pitched roofs on flat to gently sloping sites.
QUICK Cost-To-Build estimates are not available for specialty plans and construction such as garage / apartment, townhouse, multi-family, hillside, flat roof, concrete walls, log cabin, home additions, and other designs inconsistent with the assumptions outlined in Item 1 above.
User is able to select and have costs instantly calculate for slab on grade, crawlspace or full basement options.
User is able to select and have costs instantly calculate different quality levels of construction including Economy, Standard, Premium. View Quality Level Assumptions.
Estimate will dynamically adjust costs based on the home plan's finished square feet, porch, garage and bathrooms.
Estimate will dynamically adjust costs based on unique zip code for project location.
All home plans are based on the following design assumptions: 8 foot basement ceiling height, 9 foot first floor ceiling height, 8 foot second floor ceiling height (if used), gable roof; 2 dormers, average roof pitch is 12:12, 1 to 2 covered porches, porch construction on foundations.
Summarized cost report will provide approximately 70 lines of cost detail within the following home construction categories: Site Work, Foundations, Basement (if used), Exterior Shell, Special Spaces (Kitchen, Bathrooms, etc), Interior Construction, Elevators, Plumbing, Heating / AC, Electrical Systems, Appliances, Contractor Markup. View a LIVE Sample Cost Report.
QUICK Cost-To-Build generates estimates only. It is highly recommend that one employs a local builder in order to get a more accurate construction cost.
All costs are "installed costs" including material, labor and sales tax.
* Limit one $19.95 credit per complete plan package order.
** Available for U.S. only.
Previous Q & A
Previous Questions and Answers
Q:The basement option eliminates the half bath (which doesn't bother me) & the washer/dryer closet (which does). Does the basement option include hookups for the washer/dryer?
A:Yes, the washer and dryer would then go in the basement.
Date Posted: 24-May-21
Q:Would like to know the size of the main bathroom. Thanks
Date Posted: 05-Apr-21
Q:Is this plan designed for roof rafters or roof trusses?
Date Posted: 28-Jan-21
Q:Does the size of the bedrooms noted in the original drawing include the space allocated for each bedroom closet, or is the space for the closet separate from the noted bedroom size?
A:Bedroom 2 – no, it doesn’t include the garage. Bedroom 1 – yes, it does include the walk-in closet.
Date Posted: 26-Jan-21
Q:1. What are the dimensions of the 1/2 Bath? 2. What are the dimensions of the Full Bath? 3. What are the dimensions of the area (looks like washer/dryer) behind folding doors?
Date Posted: 21-Jan-21
Q:Hi! What is the vaulted ceiling height?
A:Vault peak is at about 14’-8”
Date Posted: 15-Oct-19
Q:Is the roof trust or cut an stacked
A:Roof is trussed
Date Posted: 30-Apr-19
Q:What size are the plans?
Date Posted: 21-Feb-19
Q:I would like to no if the one set of complete plans comes with the electrical and plumbing layout
A:Electrical is included. However, plumbing and HVAC are not.
Date Posted: 20-Oct-14
Q:Another question please. If I get this plan I believe I would prefer the CAD plan because of it's modification abilities. I have never used a plan from CAD format, to my knowledge. My concern is how much modification I can do. I would like to combine the two bedrooms. Eliminate the main bath and increase the size of the Master Bedroom and create a Master Bath in the front bedroom area. Would that much modification be possible with CAD, and does CAD refigure the structure specs, i.e. studs, wiring, headers, etc. ? Respectfully, Robert (Keith) McCord
A:They can modify as much as they want when they order the CAD. CAD however will not automatically reconfigure everything.
Date Posted: 03-Jul-14
Q:How could basement stairs be added to this plan or to the alternate -92388?
A:The laundry closet and pwdr room are removed to accommodate the basement stairs.
Date Posted: 26-Jun-14
Q:Are there any interior/exterior pictures or photos of this plan?
A:I regret that we have no photos on file for this design.
Date Posted: 25-Mar-14
Q:Hi, please let me know if the drawings consists of the electrical, plumbing and all related drawings to the construction, foundation, measurments, column, beams, roofing etc or it will best if you could forward me the list of your drawings
A:Our home plan set for this design consist of the following:
1. Rendering cover page
2. All 4 elevations
3. Floor plan(s)
5. Cabinet elevations
6. Window/door schedule
7. 3-D overviews
8. Foundation plan
9. 3-D joist layout
10. Roof plans with roof truss profiles
11. Cross section
12. 2009 IRC code specifications
13. (3) pages of misc. construction details
Date Posted: 22-Jan-13
Q:Can I make modifications to this plan?
A:Yes you can! Please click the "Modifications" tab above to get more information.
Q:What is the estimated price to build this plan?
A:The national average for a house is running right at $125.00 per SF. You can get more detailed information by clicking the Cost-To-Build tab above. Sorry, but we cannot give cost estimates for garage, multifamily or project plans.
