Plan Number: 58944

  • 1410 Total Living Area
  • 1410 Main Level
  • 3 Bedrooms
  • 2 Full Bath(s)
  • 2 Car Garage
  • 57' Wide x 39' Deep
Available Foundation Types:
  • Plumbing Plan

Order Code: 00WEB

  • PDF File: $805.00
  • CAD File: $1,055.00
  • Right Reading (True) Reverse: $75.00
    All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.

Plan Number 58944 | Order Code: 00WEB | Elevation

Reverse Plan


Plan Number 58944 | Order Code: 00WEB | Lower Floor Plan

Reverse Plan


Plan Number 58944 | Order Code: 00WEB | First Floor Plan

Reverse Plan

Plan Number 58944 Specifications:

  • Total Living Area: 1410
  • Main Living Area: 1410
  • Garage Type: Attached
  • Garage Bays: 2
  • House Width: 57'
  • House Depth: 39'
  • Number of Stories: 1
  • Bedrooms: 3
  • Full Baths: 2
  • Max Ridge Height: 29' from Front Door Floor Level
  • Primary Roof Pitch: 6:12
  • Roof Framing: Truss
  • Porch: 402 sq ft
  • FirePlace: Yes
  • 1st Floor Master: Yes

Available Foundation Types:

  • Plumbing Plan

Plan Number 58944 Plan Pricing:

  • PDF File: $805.00
  • 5 Sets plus PDF File: $0.00
  • CAD File: $1,055.00
  • Right Reading (True) Reverse: $75.00
    All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.

SQ. FTG. IS 1792 FOR LOWER LEVEL, BALCONY SQ. FTG. IS 278. THE HEIGHT OF THE HOUSE IS 19'-4" TO TRUSS BEARING @ 2ND FLOOR LEVEL. TOTAL HEIGHT OF HOUSE TO ROOF PEAK IS APPROX. 30'-0"
No the great room is not a vaulted ceiling. It is a flat ceiling @ 9'-0". All the rooms have a flat ceiling with a height of 9'-0".

The balcony is 35'x8' and the entry porch is 4'x28'.
