|Total Living Area:||1027 sq ft|
|Main Living Area:||763 sq ft|
|Upper Living Area:||264 sq ft|
|Unfinished Basement Area:||763 sq ft|
|See our garage plan collection. If you order a house and garage plan at the same time, you will get 10% off your total order amount.|
2x6 (option noted on wall section only)
|Number of Stories:||2|
|Max Ridge Height:||24' from Front Door Floor Level|
|Primary Roof Pitch:||12:12|
|Deck:||125 sq ft|
|1st Floor Master:||Yes|
|Main Ceiling Height:||8'|
View an actual, LIVE cost report. This report is for demo purposes only. Not plan specific.
A: The plan calls for 2x10 rafters at 16" oc over a 12' span. They are good for 95 pounds per square foot (PSF) of total load. With asphalt shingle, metal, or wood shake roofing, the allowable live load would then be 85 PSF with a dead load of 10 PSF. The house used 2x10 rafters to provide enough depth to fit R-30 insulation since the ceiling is directly mounted onto the bottom of the rafters. The house did not need 2x10 rafters for structural purposes to be buildable in most parts of the country, even areas that get heavy snow accumulations but without the deeper rafters, insufficient insulation space would have been provided.
A: Hello, One would access the plant shelf via a ladder. Your builder could build a catwalk from the balcony over to the shelf. Thanks
A: Yes you can! Please click the "Modifications" tab above to get more information.
A: The national average for a house is running right at $125.00 per SF. You can get more detailed information by clicking the Cost-To-Build tab above. Sorry, but we cannot give cost estimates for garage, multifamily or project plans.
