Basement - * $395.00 Total Living Area may increase with Basement Foundation option. Crawlspace Slab Walkout Basement - * $395.00 Total Living Area may increase with Basement Foundation option.
Materials List: $250.00 Important Notice: Material list only includes materials for the base slab and crawlspace versions. Basement and 2x6 wall options NOT included.
Right Reading (True) Reverse: $225.00
All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
**The designer's office will be closed from December 24 - January 1. Please be advised that orders will be filled January 2.**
Unlimited License To Build included with CAD file sale.
CAD file sale also includes PDF file.
Materials list will NOT reflect any options that have an additional fee because those are modifications. If you buy a materials list, it will only reflect the standard original plan. All of our CAD files are delivered in .DWG format and do not contain any type of 3D capability. Files are delivered in 2004 format so that older software versions will be able to open the files.
Available Foundation Types:
Basement
: $395.00
May require additional drawing time, please call to confirm before ordering.
Total Living Area may increase with Basement Foundation option.
Crawlspace
: No Additional Fee
Slab
: No Additional Fee
Walkout Basement
: $395.00
May require additional drawing time, please call to confirm before ordering.
Total Living Area may increase with Basement Foundation option.
Cover Sheet – May include index, front view of home, definitions, etc.
Foundation Plan – Typically includes dimensioned foundation plan with footing details.
Dimensioned Floor Plan – Electrical may be shown.
Exterior Views – Four exterior views of the residence with other miscellaneous details.
Roof Plan – Birds eye view showing all ridges, valleys and other necessary information.
Electrical Plan – Displays lighting fixtures, outlets and other necessary electrical items. These items may be shown on the Dimensioned Floor Plan. Switches are NOT shown and should be located by contractor at site.
Wall Section(s) – Detail of wall materials and assembly.
Building Section(s) – Section through home displaying necessary information about framing and other miscellaneous data.
Mechanical Plans - Because of varying site conditions, mechanical plans such as plumbing and HVAC plans are not included. These items are easily obtained by your mechanical contractor or material supplier.
Site Plans – If required, this information must be obtained locally to include the information specific to your individual property.
Structural Calculations – In certain areas, particularly those in earthquake and hurricane zones, permit departments may require you to submit structural calculations for your particular conditions. When required, you should consult with a local structural engineer.
Plan Modifications
Want to make changes?
Receive a FREE modification estimate.
Plan modification is a way of turning a stock plan into your unique custom plan. It's still just a small fraction of the price you would pay to create a home plan from scratch. We believe that modification estimates should be FREE!
We provide a modification service so that you can customize your new home plan to fit your budget and lifestyle.
Email Designer This is the best and quickest way to get a modification quote!
Please include your preferred Foundation Type and a Specific List of Changes. You can also attach a Sketch of Changes.
It's as simple as that!
Cost To Build
QUICK-Cost-To-Build Estimate
No Risk Offer: Order the QUICK-Cost-To-Build now and when you do decide to order any house plan, $24.95 will be deducted from your order! *
Get more accurate results, quicker! No need to wait for a reliable cost.
Get a detailed cost report for your home plan with over 70 lines of summarized cost information in under 5 minutes!
Cost report for your zip code. (the zip code can be changed after you receive the online report)
Estimate 1, 1-1/2 or 2 story home plans. **
Interactive! Instantly see the costs change as you vary quality levels Economy, Standard, Premium and structure such as slab, basement and crawlspace.
QUICK Cost-To-Build estimates have the following assumptions:
QUICK Cost-To-Build estimates are available for single family, stick-built, detached, 1 story, 1.5 story and 2 story home plans with attached or detached garages, pitched roofs on flat to gently sloping sites.
QUICK Cost-To-Build estimates are not available for specialty plans and construction such as garage / apartment, townhouse, multi-family, hillside, flat roof, concrete walls, log cabin, home additions, and other designs inconsistent with the assumptions outlined in Item 1 above.
User is able to select and have costs instantly calculate for slab on grade, crawlspace or full basement options.
User is able to select and have costs instantly calculate different quality levels of construction including Economy, Standard, Premium. View Quality Level Assumptions.
Estimate will dynamically adjust costs based on the home plan's finished square feet, porch, garage and bathrooms.
Estimate will dynamically adjust costs based on unique zip code for project location.
All home plans are based on the following design assumptions: 8 foot basement ceiling height, 9 foot first floor ceiling height, 8 foot second floor ceiling height (if used), gable roof; 2 dormers, average roof pitch is 12:12, 1 to 2 covered porches, porch construction on foundations.
Summarized cost report will provide approximately 70 lines of cost detail within the following home construction categories: Site Work, Foundations, Basement (if used), Exterior Shell, Special Spaces (Kitchen, Bathrooms, etc), Interior Construction, Elevators, Plumbing, Heating / AC, Electrical Systems, Appliances, Contractor Markup. View a LIVE Sample Cost Report.
QUICK Cost-To-Build generates estimates only. It is highly recommend that one employs a local builder in order to get a more accurate construction cost.
All costs are "installed costs" including material, labor and sales tax.
* Limit one $24.95 credit per complete plan package order.
** Available for U.S. only.
Previous Q & A
Previous Questions and Answers
Q:In the master bedroom. What is the length of the bottom wall from the
left wall to the opening of the door leading into the bedroom.
Also what is the length of the bottom wall from the right wall to the
opening of the door leading into the bedroom.
Thank you very much.
Q:Could you please give me the length of the wall starting at the front
door up to where the opening starts for going into the entry?
Thank you so much.
A:Approximately 13'-6"
Q:what are the dimensions of the bedroom closets in bedroom 2&3. What is the length of the bare wall in the kitchen that extends from the end of the cabinets to the door of the great room
A:Closets - 2-4 x 6-4
Wall - approximately 6-6
Q:Do the plans meet 2015 International Building Code?
A:Since this is a single family dwelling, it would fall under the jurisdiction of the International Residential Code and not the International Building Code. This particular plan conforms to the 2018 edition of the Residential Code.
Q:What size are the two large windows on the front of the house?
A:Great Room is a double 2870 and bedroom is a double 2860.
Q:Please send me the width of the kitchen window. It looks like a double window online. I am trying to figure out if a wide sink I am looking out will work with this plan. Thanks
A:The actual width will depend on what windows you select. The plans call for a double 2830 (2-8 wide x 3-0 tall). The total width will depend on the width of the mull that the manufacturer uses for a double window. If you need exact sizes, you will have to contact a window sales company and select a specific brand/style of window before they can give you a total width.
Q:What dimensions are the kitchen and great room windows?
A:Great Room -2870 double
Kitchen - 2830 double
Q:What are all of the window dimensions in each of the rooms?
A:The window sizes for each window will be provided on the construction documents. There are multiple different sizes, but each are labeled with the size on the floorplan that you receive with your order.
Q:If I order 5 sets plus PDF File, is the scale 1/4" for floor plan and elevations? Also, how many pages is included in a set?
A:See below for the sheet index of included pages. The scale for the floorplan and elevations are 1/4" as long as they are printed on 24"x36" paper as "actual size".
Cover Sheet, showing architectural rendering of the residence
Foundation Plan
Floor Plan/Plans
Exterior Views
Sections & Cabinets
Electrical Plan
Roof Plan
Q:How do you total the sq footage? When I add the rooms up its only 1,440 ish & that's hall, closets & stairs included.
A:You cannot add the room dimensions and come up with the total square footage. The room sizes given only represent the interior dimensions of each space, so the wall areas as well as spaces not labeled with dimensions would not be included in that scenario. The heated area is represented on the floor plan image by all areas shown in yellow. That space is the 1521. Unheated areas are shown in blue.
Q:Is there a materials list available for this plan?
A:There is a materials list available for $195. It is only available for the original slab version of the plan. Any other options (2x6 walls, basement, etc.) will not be reflected.
Q:Could you forward the walkout rear elevation and floor plan? Thanks
A:Good Morning,
This is a new plan and no one has purchased the walkout basement option yet. Therefore we do not have a rear elevation available. Our typical walkout elevation will mimic the door and window layout of the main floor on the basement level below. Also, please keep in mind that all of our basement options are UNFINISHED which means that there will not be a floorplan for the basement level.
Thanks,
Jason
Q:hi there,wondering if the 6 foot bar width is the widest you can go while still allowing for code requirement space between the island and their adjacent cabinets on both sides . Essentially, could the island be wider and still allow for proper space?
A:Currently, there is 4' between each end of the island and the adjacent cabinets. That could be squeezed to 3-6 giving you another 12" in width on the island.
Thanks,
Common Questions:
Q:Can I make modifications to this plan?
A:Yes you can! Please click the "Modifications" tab above to get more information.
Q:What is the estimated price to build this plan?
A:The national average for a house is running right at $125.00 per SF. You can get more detailed information by clicking the Cost-To-Build tab above. Sorry, but we cannot give cost estimates for garage, multifamily or project plans.
