5 Car Garage Plan 69917

Specifications

Garage Area:	1875 sq ft
Garage Type:	Detached
Garage Bays:	5
Foundation Types:	Not Applicable
Exterior Walls:	2x4
House Width:	50'
House Depth:	50'
Number of Stories:	1
Max Ridge Height:	16'8 from Front Door Floor Level
Primary Roof Pitch:	8:12
Roof Framing:	Stick
Main Ceiling Height:	8'

Pricing

• PDF File: $300.00
• 1 Set: $250.00
• 5 Sets: $300.00
• Reproducible Set: $400.00
• CAD File: $650.00
  Single Build License issued on CAD File orders.
• Right Reading (True) Reverse: $200.00
  All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
• Additional Sets: $50.00

Available Foundation Types:

• Not Applicable

Available Exterior Wall Types:

• 2x4: No Additional Fee

Prices subject to approval prior to fulfillment.

• Shipping Policy

What is Included in this House Plan?

1/4" scale floor plan (or plans), electrical and plumbing noted directly on plan(s) no mechanical layouts available.

1/4" scale front elevation

Rear page with 1/4" scale rear elevation, 1/8" scale side elevations and roof detail

No foundation design included. Due to the wide variety of soil conditions and various building practices, there is no way we could provide accurate drawings to cover all situations. A registered professional engineer should design the foundation for your specific lot. We believe something this important should not use generic drawings. Where we are located, most municipalities, FHA/VA, and all the builder warranty programs require the foundations to be designed by a registered structural engineer.

Standard detail page with electrical legends, typical building section, building code notes, etc.

Want to make changes?

Receive a FREE modification estimate in one of 3 ways. Our modification team is ready to help you adjust any plan to fit your needs. The ReDesign process is simple and estimates are free!

1. Complete this On-Line Request Form

2. Print, complete and fax this PDF Form to us at 1-800-675-4916.

3. Want to talk to an expert? Call us at 913-938-8097 (Canadian customers, please call 800-361-7526) to discuss modifications.

Note: - a sketch of the changes or the website floor plan marked up to reflect changes is a great way to convey the modifications in addition to a written list.

We Work Fast!

When you submit your ReDesign request, a designer will contact you within 24 business hours with a quote.
You can have your plan redesigned in as little as 14 - 21 days!

We look forward to hearing from you!

Start today planning for tomorrow!

Common Questions:

Got a question about this plan? Ask the Designer any question you may have. NOTE: If you have a plan modification question, please click on the Plan Modifications tab above.
