Mediterranean Style House Plan 75909

Specifications

Total Living Area:	4100 sq ft
Main Living Area:	4100 sq ft
Garage Area:	1007 sq ft
Garage Type:	Attached
Garage Bays:	3
Foundation Types:	Stem Wall Slab
Exterior Walls:	2x6 - * $500.00 Concrete
House Width:	75'
House Depth:	127'6
Number of Stories:	1
Bedrooms:	4
Full Baths:	4
Half Baths:	1
Max Ridge Height:	25'2 from Front Door Floor Level
Primary Roof Pitch:	6:12
Roof Framing:	Truss
Porch:	948 sq ft
FirePlace:	Yes
1st Floor Master:	Yes
Main Ceiling Height:	10'

* May require additional drawing time.

Special Features:

• Outdoor Kitchen
• Outdoor Pool
• Rear Porch

Pricing

• PDF File: $2,857.14
• Reproducible Set: $2,857.14
• CAD File: $2,857.14
  Single Build License issued on CAD File orders.
• Right Reading (True) Reverse: $350.00
  All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.

THIS PLAN CANNOT BE SOLD FOR CONSTRUCTION ANYWHERE IN THE STATE OF FLORIDA WITHOUT DESIGNER APPROVAL. Please call for availability.

Available Foundation Types:

• Stem Wall Slab : No Additional Fee

Available Exterior Wall Types:

• 2x6: $500.00
  (Please call for drawing time.)
• Concrete: No Additional Fee

Prices subject to approval prior to fulfillment.
