CAD File: $3,845.00 Single Build License issued on CAD File orders.
Concerning PDF or CAD File Orders: Designer requires that a End User License Agreement be signed before fulfilling PDF and CAD File order.
Right Reading (True) Reverse: $350.00
All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
Need Prints?
It seems that this plan only offers electronic (PDF or CAD) files. If you also need Printed Sets, please call 1-800-482-0464, x403 to discuss possible options.
Additional Notes
Copyrighted plan not released for build unless approved by Designer.
$95.00 to add a PDF File to a CAD file order. Call the sales office to add this option to your order.
Available Foundation Types:
Walkout Basement
: No Additional Fee
Total Living Area may increase with Basement Foundation option.
1. Exterior elevations – Included are front, rear, left and right side views of the exterior of the house. Exterior materials, construction details and measurements are also noted.
2. Foundation Plan – Includes layout of foundation support walls, plus excavated and unexcavated areas, if applicable.
3. Detailed Floor Plans – These plans show the layout of each floor of the house, including room dimensions, window and doors sizes and keys for cross section details provided later in the plans. Engineered floor joist, ceiling joist and roof plans are not included in some plans. Local engineers or manufacturing engineers are widely available to supply the services that apply to local geographic conditions.
4. Interior Details – These drawings show the specific details and design of special interior features.
5. Roof Plan – Includes the overall layout for roof construction. If trusses are used, we recommend using a local truss manufacturer to ensure compliance with local codes and regulations.
6. Cross Section Details – Important changes in floor, ceiling and roof heights or the relationship of one level to another are called out. Exterior details such as railing and banding may also be shown.
7. Electrical – Electrical floor plan schematics for 1st and 2nd floors.
Plan Modifications
Want to make changes?
Receive a FREE modification estimate.
Plan modification is a way of turning a stock plan into your unique custom plan. It's still just a small fraction of the price you would pay to create a home plan from scratch. We believe that modification estimates should be FREE!
We provide a modification service so that you can customize your new home plan to fit your budget and lifestyle.
Click to Email Us This is the best and quickest way to get a modification quote!
Please include your preferred Foundation Type and a Specific List of Changes. You can also attach a Sketch of Changes.
It's as simple as that!
Cost To Build
QUICK-Cost-To-Build Estimate
No Risk Offer: Order the QUICK-Cost-To-Build now and when you do decide to order any house plan, $24.95 will be deducted from your order! *
Get more accurate results, quicker! No need to wait for a reliable cost.
Get a detailed cost report for your home plan with over 70 lines of summarized cost information in under 5 minutes!
Cost report for your zip code. (the zip code can be changed after you receive the online report)
Estimate 1, 1-1/2 or 2 story home plans. **
Interactive! Instantly see the costs change as you vary quality levels Economy, Standard, Premium and structure such as slab, basement and crawlspace.
QUICK Cost-To-Build estimates have the following assumptions:
QUICK Cost-To-Build estimates are available for single family, stick-built, detached, 1 story, 1.5 story and 2 story home plans with attached or detached garages, pitched roofs on flat to gently sloping sites.
QUICK Cost-To-Build estimates are not available for specialty plans and construction such as garage / apartment, townhouse, multi-family, hillside, flat roof, concrete walls, log cabin, home additions, and other designs inconsistent with the assumptions outlined in Item 1 above.
User is able to select and have costs instantly calculate for slab on grade, crawlspace or full basement options.
User is able to select and have costs instantly calculate different quality levels of construction including Economy, Standard, Premium. View Quality Level Assumptions.
Estimate will dynamically adjust costs based on the home plan's finished square feet, porch, garage and bathrooms.
Estimate will dynamically adjust costs based on unique zip code for project location.
All home plans are based on the following design assumptions: 8 foot basement ceiling height, 9 foot first floor ceiling height, 8 foot second floor ceiling height (if used), gable roof; 2 dormers, average roof pitch is 12:12, 1 to 2 covered porches, porch construction on foundations.
Summarized cost report will provide approximately 70 lines of cost detail within the following home construction categories: Site Work, Foundations, Basement (if used), Exterior Shell, Special Spaces (Kitchen, Bathrooms, etc), Interior Construction, Elevators, Plumbing, Heating / AC, Electrical Systems, Appliances, Contractor Markup. View a LIVE Sample Cost Report.
QUICK Cost-To-Build generates estimates only. It is highly recommend that one employs a local builder in order to get a more accurate construction cost.
All costs are "installed costs" including material, labor and sales tax.
* Limit one $24.95 credit per complete plan package order.
** Available for U.S. only.
Previous Q & A
Previous Questions and Answers
Q:Good afternoon. I'm interested in House Plan 97680 that I would like to get the cad file. What drawings will I receive and am I able to modify anything to include text, foundation, details, title sheet, etc. Thank you!
A:What we provide is an architectural set of plans that are designed per IBC (International Building Code) guidelines and are not designed per local codes. Our plans are well-dimensioned working drawing sets and do not include structural plans. A set will include front, rear, and side elevations, first floor, second floor, foundation plan, roof plan, schematic electrical plans, sections, and details pertaining to this plan.
All engineering must be completed by a local engineer and/or truss manufacturer/supplier. Truss manufacturers and suppliers typically supply engineered structural floor and roof framing plans at no charge if the framing materials are purchased from their respective companies.
The PDF/CAD file agreement is stating that you are the purchaser of the 1-time license to build this design. No one else has the right to build from your purchased plans. Your plans can be provided to anyone involved in your building project for the 1-time build of your home. There is no expiration date on your 1-time license to build your custom home design.
The CAD file is the "master file" of the design. It has all functions, from printing to making changes and saving. Customers may change or modify the Plans/Cad files, thereby creating a derivative work of the Plans/Cad files. However, GarrellAssociates.com retains full rights and title to any such derivative work, except as specifically licensed to the customer under this License Agreement.
The Builder note is only used in special circumstances for builders who are developing a subdivision and will be building the home more than once on a Re-Use fee schedule. This note is not valid if it is not filled out by a Garrell Associates, Inc. employee with an actual expiration date and Re-Use fee schedule.
1-time license to build this design. No one else has the right to build from your purchased plans. Your plans can be provided to anyone involved in your building project for the 1-time build of your home. There is no expiration date on your 1 time licensed to build your custom home design.
If you have any more questions or need help, please don't hesitate to let us know.
Q:How many sq ft is Plan # 97680 on the main floor without the terrace/basement.
A:First Floor - 3840 sq.ft.
I have attached the Square feet Calculation for your reference.
Q:What is the square footage of the basement? Thank you.
A:The approximate square footage of the basement is 2794 HSF.
Q:What is the square footage of the deck, the covered screened porch and the covered porch?
A:Square footage of the deck, covered screened porch and covered porch is 1072 square feet.
Q:What is the color of the stone and roof
A:Unfortunately we do not have the color package for the exteriors and roof for this plan. The homeowner and the builder select the colors. You may be able to take the photograph to a local paint supplier or siding company and have them match the color.
Q:How many square feet are on the main level not counting the garage or bonus area? Also, what size attic does this house have?
A:Plan #97680:
The first floor square footage is 3480 s.f. The basement square footage is an additional +/-2794 s.f.
Attic size is determined by you and your builder. It will depend on the
type of roof system you use. It is designed for a stick built roof.
Thank you
Q:What is the total sq footage of the basement?
A:The basement square footage is +/-2794 s.f.
Common Questions:
Q:Can I make modifications to this plan?
A:Yes you can! Please click the "Modifications" tab above to get more information.
Q:What is the estimated price to build this plan?
A:The national average for a house is running right at $125.00 per SF. You can get more detailed information by clicking the Cost-To-Build tab above. Sorry, but we cannot give cost estimates for garage, multifamily or project plans.
Ask A Question
Got a question about this plan? Ask the Designer any question you may have. NOTE: If you have a plan modification question, please click on the Plan Modifications tab above.
Our Low Price Guarantee
If you find the exact same plan featured on a competitor's web site at a lower price, advertised OR special SALE price, we will beat the competitor's price by 5% of the total, not just 5% of the difference! To take advantage of our guarantee, please call us at 800-482-0464 or email us the website and plan number when you are ready to order. Our guarantee extends up to 4 weeks after your purchase, so you know you can buy now with confidence.
