|Total Living Area:||1561 sq ft|
|Main Living Area:||1064 sq ft|
|Upper Living Area:||497 sq ft|
|Unfinished Basement Area:||1064 sq ft|
|Garage Area:||528 sq ft|
|Foundation Types:||Basement - * $295.00
Total Living Area may increase with Basement Foundation option.
|Number of Stories:||2|
|Max Ridge Height:||26' from Front Door Floor Level|
|Primary Roof Pitch:||12:12|
|Porch:||36 sq ft|
|Main Ceiling Height:||8'|
|Upper Ceiling Height:||8'|
View an actual, LIVE cost report. This report is for demo purposes only. Not plan specific.
A: The hall width between bedroom two and the bathroom is 4.2 clear The hall width between bedroom two and the staircase is 3.6 clear The with of the staircase is 3 foot clear
A: The same as the main level But not the garage or decks
A: The answer is not as simple as you think The house is designed using trusses, your truss supplier will adjust the product to the local requirements. And Wind loads are adjusted locally as well What the plans specify I will show below, varies with the type of roofing you choose, and can be adjusted for local needs This is what is shown on the plans Roof Loads For Wood, asphalt or fiberglass shingles Live load 50, Dead load 15 Total load 65 PSF Concrete tiles Live load 50 Dead load 25 Total load 75 PSF Built up roof Live Load 50 Dead load 19 Total load 69 PSF
A: The MAXIMUM grade to ridge height, which is located on the walk-out Basement side, is 33 foot 6 inches. On the high grade side, grade to ridge is 25 foot 9 inches. The Garage roof ridge is 20 foot 9 inches from grade.
A: Square footage of basement is 1064.View Attached File
A: You will be adding on the main floor about 820 square feet and the upper floor (assuming you leave the open to above area as is and do not increase the depth of the bedroom) about 400 square feet. Total increase 1220 Total new square footage would be about 2781
A: The garage is 24'x22', the house is 28'x40' to the front prow not incl. decks. The overall maximum footprint would be 28'x62' of the house only. Additionally, the balcony at the left side is 4'-0" wide, the sundeck at the front projects 12' from the prow. The prow projects 4' from the house so 36'+4' gives you the 40'
A: The Master Suite has an 8'-0" flat ceiling as indicated by the dotted lines and then slopes down to the outer walls. The stove is vented downwards using a Jenn-Air type cooktop/range unit. The full basement is unfinished other than the support walls, the builder could help you finish it according to your specifications.
A: The total square footage is 1561 the square footage does not include the garage area.
The same plan is available without a garage it is plan #99914 this plan
can also be ordered with a walkout basement for an add on fee of $150.00
A: Yes you can! Please click the "Modifications" tab above to get more information.
A: The national average for a house is running right at $125.00 per SF. You can get more detailed information by clicking the Cost-To-Build tab above. Sorry, but we cannot give cost estimates for garage, multifamily or project plans.
