Foundation Plan and Details (plan scale: 1/4" = 1'-0"; details: 3/4"=1'-0")
Short-form FHA/VA Specifications form
License to Build
Plans range in number of pages from 5 to 13 pages on 24" x 36" sheets. Printed on a wide-format xerox machine to guarantee quality of the prints and very good legibility. Prints are printed on white bond paper. Reproducible plans are printed on eraseable vellum.
This Plan is a USDA Rural Development Certified Plan
Want to make changes?
Our modification team is ready to help you adjust this plan to fit your needs. Receive a FREE modification estimate by completing this form.
Cost To Build
No Risk Offer: Order the QUICK-Cost-To-Build now and when you do decide to order any house plan, $29.95 will be deducted from your order! *
Get more accurate results, quicker! No need to wait for a reliable cost.
Get a detailed cost report for your home plan with over 70 lines of summarized cost information in under 5 minutes!
Cost report for your zip code. (the zip code can be changed after you receive the online report)
Estimate 1, 1-1/2 or 2 story home plans. **
Interactive! Instantly see the costs change as you vary quality levels Economy, Standard, Premium and structure such as slab, basement and crawlspace.
QUICK Cost-To-Build estimates have the following assumptions:
QUICK Cost-To-Build estimates are available for single family, stick-built, detached, 1 story, 1.5 story and 2 story home plans with attached or detached garages, pitched roofs on flat to gently sloping sites.
QUICK Cost-To-Build estimates are not available for specialty plans and construction such as garage / apartment, townhouse, multi-family, hillside, flat roof, concrete walls, log cabin, home additions, and other designs inconsistent with the assumptions outlined in Item 1 above.
User is able to select and have costs instantly calculate for slab on grade, crawlspace or full basement options.
User is able to select and have costs instantly calculate different quality levels of construction including Economy, Standard, Premium. View Quality Level Assumptions.
Estimate will dynamically adjust costs based on the home plan's finished square feet, porch, garage and bathrooms.
Estimate will dynamically adjust costs based on unique zip code for project location.
All home plans are based on the following design assumptions: 8 foot basement ceiling height, 9 foot first floor ceiling height, 8 foot second floor ceiling height (if used), gable roof; 2 dormers, average roof pitch is 12:12, 1 to 2 covered porches, porch construction on foundations.
Summarized cost report will provide approximately 70 lines of cost detail within the following home construction categories: Site Work, Foundations, Basement (if used), Exterior Shell, Special Spaces (Kitchen, Bathrooms, etc), Interior Construction, Elevators, Plumbing, Heating / AC, Electrical Systems, Appliances, Contractor Markup. View a LIVE Sample Cost Report.
QUICK Cost-To-Build generates estimates only. It is highly recommend that one employs a local builder in order to get a more accurate construction cost.
All costs are "installed costs" including material, labor and sales tax.
* Limit one $29.95 credit per complete plan package order.
** Available for U.S. only.
Previous Q & A
Previous Questions and Answers
Q:What are the dimensions of the workshop?
A:7'-10" wide by 11' deep is the size of the workshop.
Date Posted: 15-Mar-21
Q:Is it possible to make the plans bigger We want ( my husband) s around 3000 ft home, the plans that I like is around 1800 We are in the looking stage , goal is to start building around 4-2019
A:Hello, This plan is 3000 s.f. already. It is possible to modify an 1800 s.f. house to be 3000. Just submit a picture or sketch of whatever it is you like, and we can provide a quote.
Date Posted: 23-Mar-18
Q:what are the dimensions of the upstairs bath ? The one at the end of the hall. Thanks
A:Hello, The bathroom is 5'-6" wide, and the sinks are 6 feet long. The tub/toilet area is 5'-9" from door to back side of tub. There is additional attic space on the right, and to the rear of that bathroom, so it could be enlarged easily, if desired.
The other upstairs bath is 5 feet wide, by 8'-6" deep.
Date Posted: 03-Dec-14
Q:a few questions on the master bath so i can get my math correct. What is the width of the area between the 2 closet doors? What is the distance between the vanities and the tub/shower area? What is the size of the shower, the commode and the jet tub? Thanks so much for your help!
A:Good morning, The width of the hall between the closets is 3’-10” clear. There is four feet clear from the corner of the toilet room wall to the edge of the sink counter. The shower is 48” wide and 42” deep, the Toilet room is 42” deep and 4’-8” wide (clear), the tub is a 72” long and 42” wide unit. (That is the size of the whole space from wall to wall. Hope this helps you. God bless!
Date Posted: 20-Jan-10
Q:Can I make modifications to this plan?
A:Yes you can! Please click the "Modifications" tab above to get more information.
Q:What is the estimated price to build this plan?
A:The national average for a house is running right at $125.00 per SF. You can get more detailed information by clicking the Cost-To-Build tab above. Sorry, but we cannot give cost estimates for garage, multifamily or project plans.
