Foundation Plan and Details (plan scale: 1/4" = 1'-0"; details: 3/4"=1'-0")
Short-form FHA/VA Specifications form
License to Build
Plans range in number of pages from 5 to 13 pages on 24" x 36" sheets. Any plan less than 1200 heated sq ft is formatted on 18x24 size paper. Printed on a wide-format xerox machine to guarantee quality of the prints and very good legibility. Prints are printed on white bond paper. Reproducible plans are printed on eraseable vellum.
This Plan is a USDA Rural Development Certified Plan
Plan Modifications
Want to make changes?
Receive a FREE modification estimate:
Plan modification is a way of turning a stock plan into your unique custom plan. It's still just a small fraction of the price you would pay to create a home plan from scratch. We believe that modification estimates should be FREE!
We provide a modification service so that you can customize your new home plan to fit your budget and lifestyle.
Simply contact the modification department via...
Email Us This is the best and quickest way to get a modification quote!
Please include your Telephone Number, Plan Number, Foundation Type, State you are building in and a Specific List of Changes.
It's as simple as that!
Cost To Build
What will it cost to build your new home?
Let us help you find out!
COOLhouseplans.com has partnered with Home-Cost.com to provide you the most accurate, interactive online estimator available. Home-Cost.com is a proven leader in residential cost estimating software for over 20 years.
No Risk Offer: Order your Home-Cost Estimate now for just $29.95! We will provide you with a discount code in your receipt for when you decide to order any plan on our website than will more than pay you back for ordering an estimate.
Accurate. Fast. Trusted. Construction Cost Estimates That Save You Time and Money.
$29.95 per plan
** Available for U.S. and Canada
With your 30-day online cost-to-build estimate you can start enjoying these benefits today.
INSTANT RESULTS: Immediate turnaround—no need to wait days for a cost report.
RELIABLE: Gain peace of mind and confidence that comes with a reliable cost estimate for your custom home.
INTERACTIVE: Instantly see how costs change as you vary design options and quality levels of materials!
REDUCE RISK: Minimize potential cost overruns by becoming empowered to make smart design decisions. Get estimates that save thousands in costly errors.
PEACE OF MIND: Take the financial guesswork out of building your dream home.
DETAILED COSTING: Detailed, data-backed estimates with +/-120 lines of costs / options for your project.
EDITABLE COSTS: Edit the line-item labor & material price with the “Add/Deduct” field if you want to change a cost.
Q:The measurements on the bedrooms the measurements shown is that including the depth in the closet?
A:No. The room sizes are clear useable inside the bedroom, not including the closet area.
Q:Hi ! Can this plan be altered so the Rafters won't show in the ceiling of the Great Room? Would the ceiling have to be lowered or changed to a non vaulted ceiling..... Thanks Jarvis Massey
A:Hello, The rafters in the great room are not exposed. What you see are decorative beams that have been added to the drywall ceiling . The true rafters are hidden above the drywall.
If you do not like the false beam look, just omit that feature when you build. No need to modify the plans.
Thanks.
Modification Department
Q:Hi! Could you tell me if it is possible to add an upstairs bonus room to this plan? With a closet and a bathroom? Thank you! Molly Crawford
A:Hello, We are the designer of this plan you found at www.FamilyHomePlans.com.
The fee to add a Bonus Room with closet and bathroom would be $495.00 in addition to the purchase of the 5 set or the PDF plan package.
When you are ready to proceed, please call the website to place your order for the plan package. Be sure to tell them that you are having modifications done by the designer. They will process the order, and send a copy to us. We will then proceed with preliminary plans for your review. We would request payment for the modification fees when we complete the work.
Please allow 8 to 12 working days for preliminary plans, and an additional 12 to 20 working days for final plans to be completed.
Amanda
-----------
House Plan Gallery, Inc.
Special Note: Customized materials list are not included in this quote. If you purchase the online material list, it will match the ORIGINAL plans NOT the customized set. We do not offer customized materials list at this time. Local builders and carpenters are the best source for those.
Q:Where are the utilities/utility room in this plan? Water heater, furnace, etc.
A:Hello, Predrawn house plans do not include mechanical plans. Mechanical includes Heat and ac plans, plumbing plans, etc..
The layout and location of those items depends on many variables, your budget, foundation options, etc..
If you choose the basement foundation option, the mechanical area can be below.
If you choose slab or crawlspace, there would be two heat/ac units, both located in the attic space, unless you wish to designate a 3'x3' closet somewhere on the main floor.
Water heaters depend on your budget and choices too. Most often people choose the tankless type, which can be mounted on any exterior wall, interior wall, in the attic, in a closet, etc... If you choose the conventional water heaters with a tank, they would go in the attic with a catch pan under them, or you can designate a closet space on the first floor. The hall closet near the master bedroom would work well for both one hvac unit, and one water heater. The closet in the hallway on the left end could be used for a water heater, but is not big enough for a heat and ac unit.
There is a large attic available over the entire house which can be used for any of those items.
Q:I'm interested in purchasing the CAD File of plan 59947. Our architect is asking if the CAD File includes more than just the floorplan. We have a few changes we'd like to make but he needs to be certain that he'd be able to make those changes with the CAD File listed here. Thank you!
A:Hello, The CAD files contain the full set of working drawings including these items-
Foundation plan with typical details
Floor plans
Four exterior elevations
Roof plan
Roof framing
ceiling framing
Full cross section
Wall section
Stair section (if it has stairs)
Misc. Structural details as needed.
Electrical layout of Lighting, outlets, smoke detectors, etc..
Interior cabinet drawings
Few other misc. helpful items such as lumber span tables, etc...
Predrawn house plans do NOT include Plumbing, Heat and ac layout, site plans, or anything other than the items listed above.
Plans are designed for the International Residential Code in effect at the time and place the plans were created. Probably 2006 version.
Thanks.
Q:Where do the steps to,for the basement and can there be steps in the garage to the basement?
A:See plan 59978 for the basement version.
Q:Does this plan set (59947) come with:
Electrical
Plumbing
Framing with details
Foundation with details
Trusses
Mechanical
Structural with details
Or what other details are provided
Thanks
Chris Robinson
A:Hello Chris, These plans contain the following items- Cover sheet with notes, foundation plan with typical details, floor plans, four exterior elevations, roof plan, roof framing (stick built, not trusses), ceiling framing, wall section, full cross section through house, interior cabinet drawings, electrical layout, misc. structural details as required.
Predrawn house plans do not, and cannot come with plumbing, or mechanical (heat and air) plans. Those items are site specific and change drastically depending on many factors, including local codes, solar orientation, insulation choices, local codes, equipment used, etc..etc.etc.. There is simply no way to produce a plumbing or heat and air plan that would be useable for people outside of any given area. These items must be done by someone familiar with your local codes, and knowledge of your specific site conditions, etc....
If someone else claims to include those items, they would have to be just some sort of generic layout, which would be pretty useless to most people.
If you wish to use prefab roof trusses, simply provide a copy of the plans to the local truss manufacturer, and they will engineer and build the trusses to meet your local codes, and needs. Even if the plan did show trusses, the local truss manufacturer would still have to design them for your local wind and snow, and/ or seismic loads.
Have a great day and God bless!
Common Questions:
Q:Can I make modifications to this plan?
A:Yes you can! Please click the "Modifications" tab above to get more information.
Q:What is the estimated price to build this plan?
A:The national average for a house is running right at $125.00 per SF. You can get more detailed information by clicking the Cost-To-Build tab above. Sorry, but we cannot give cost estimates for garage, multifamily or project plans.
