Mediterranean Style House Plan 60586

Specifications

Total Living Area:	4880 sq ft
Lower Living Area:	288 sq ft
Main Living Area:	2895 sq ft
Upper Living Area:	1697 sq ft
Garage Area:	2602 sq ft
Garage Type:	Drive Under
Garage Bays:	4
Foundation Types:	Pile
Exterior Walls:	Concrete
House Width:	64'
House Depth:	64'8
Number of Stories:	3
Bedrooms:	4
Full Baths:	5
Half Baths:	1
Max Ridge Height:	43'7 from Front Door Floor Level
Primary Roof Pitch:	6:12
Roof Framing:	Truss
Porch:	1201 sq ft
Deck:	546 sq ft
Formal Dining Room:	Yes
FirePlace:	Yes

Special Features:

• Deck or Patio
• Outdoor Pool
• Rear Porch

Pricing

• PDF File: $4,428.57
• Reproducible Set: $4,428.57
• CAD File: $4,428.57
  Single Build License issued on CAD File orders.
• Right Reading (True) Reverse: $500.00
  All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.

THIS PLAN CANNOT BE SOLD FOR CONSTRUCTION ANYWHERE IN THE STATE OF FLORIDA WITHOUT DESIGNER APPROVAL. Please call for availability.

Available Foundation Types:

• Pile : No Additional Fee

Available Exterior Wall Types:

• Concrete: No Additional Fee

Prices subject to approval prior to fulfillment.
