|Total Living Area:||2482 sq ft|
|Main Living Area:||2482 sq ft|
|Bonus Area:||473 sq ft|
|Garage Area:||695 sq ft|
|Foundation Types:||Basement - * $395.00
Total Living Area may increase with Basement Foundation option.
Walkout Basement - * $395.00
Total Living Area may increase with Basement Foundation option.
2x6 - * $245.00
|Number of Stories:||1|
|Max Ridge Height:||29'4 from Front Door Floor Level|
|Primary Roof Pitch:||12:12|
|Roof Load:||20 psf|
|Porch:||196 sq ft|
|Formal Dining Room:||Yes|
|1st Floor Master:||Yes|
|Main Ceiling Height:||9' & 10'|
|Upper Ceiling Height:||9'|
