Ranch Style House Plan 75171
2486 Sq Ft, 3 Bedrooms, 2 Full Baths, 1 Half Baths, 2 Car Garage
Quick Specs
2486 Total Living Area2486 Main Level
3 Bedrooms
2 Full Baths, 1 Half Baths
2 Car Garage
82'11 W x 60'10 D
Quick Pricing
PDF File: $1,295.005 Sets: $1,495.00
5 Sets plus PDF File: $1,595.00
CAD File: $2,295.00
Plan Specifications
Specifications
| Total Living Area: | 2486 sq ft |
| Main Living Area: | 2486 sq ft |
| Garage Area: | 506 sq ft |
| Garage Type: | Attached |
| Garage Bays: | 2 |
| Foundation Types: | Slab |
| Exterior Walls: | 2x6 - * $345.00 Metal |
| House Width: | 82'11 |
| House Depth: | 60'10 |
| Number of Stories: | 1 |
| Bedrooms: | 3 |
| Full Baths: | 2 |
| Half Baths: | 1 |
| Max Ridge Height: | 22'0 from Front Door Floor Level |
| Primary Roof Pitch: | 5:12 |
| Roof Framing: | Metal |
| Porch: | 831 sq ft |
| FirePlace: | Yes |
| Main Ceiling Height: | 9' |
Special Features:
Plan Package Pricing
Pricing
Available Foundation Types:
Available Exterior Wall Types:
Prices subject to approval prior to fulfillment.What's Included?
What is Included in this House Plan?
Our working drawings include the following..We use AutoCAD to produce our working drawings. This allows us to be 100% accurate on our dimensions as well as coordinate all drawings with the highest level of precision. Below are examples of what comes in each working drawing set...
Floor Plans - For each level we include... a 1/4"=1'-0" scale floor plan indicating frame walls and masonry with dimensions, notes, door and window sizes, room names and floor finishes, cabinet, shelving, fixture locations and notes, ceiling conditions, electrical/lighting fixtures and switches.
Exterior Elevations - We include... Front Elevation at 1/4"=1'-0", side and rear elevations at 1/8"=1'-0", plate heights, roof overhangs, material/surface notes, window heights, roof pitches, material hatching for clarity, floor to floor dimensions and any other detail we feel is necessary to explain the construction.
Cabinets/Building Sections- Cabinet elevations at 3/8"=1'-0", showing cabinets, appliance locations, plumbing fixtures, shelving, counter/backsplash surface, cabinet material and finish, niche details and any other special situation that cannot be understood from the plan view. Building Sections are included only when there is no other way to indicate the spatial characteristics of the home. This information is quite often indicated well enough on the elevations and plans.
Foundation Plans - We offer a choice of three types of foundations, full basement, crawlspace, and slab foundations. Each comes fully dimensioned, and noted indicating wall composition and thickness, construction detail references to our detail page, beam, pier and column locations and sizes, stair locations for basements, reinforcing steel sizes and step downs in monolithic slabs and ventilation grilles for crawlspaces.
Framing Plans - For each level we include... a 1/8"=1'-0" scale plan indicating rafter, ceiling and floor joists locations, sizes and spacing as well as lumber grade specified, additional bracing and blocking.
Details - For each foundation type we include... 3/4"=1'-0" scale details indicating material composition, size and critical dimensions for construction of the primary foundation.
Plan Modifications
Want to make changes?
Plan modification is a way of turning a stock plan into your unique custom plan. It's still just a small fraction of the price you would pay to create a home plan from scratch. You will receive a FREE, no obligation, modification estimate to get exactly the home plan you've been dreaming of. Simply contact the modification department 1 of 3 ways:Call 866-465-5866 and talk to a live person that can give you and FREE modification estimate over the phone!
Email Us - Please Include your telephone number, plan number, foundation type, state you are building in and a specific list of changes.
Fax: 651-602-5050 - Make sure to include a cover sheet with your contact info. Make attention to the COOLhouseplans.com Modification Department.
Cost To Build
What will it cost to build your new home?
Let us help you find out!
Accurate. Fast. Trusted.
Construction Cost Estimates That Save You Time and Money.
$29.95 per plan
** Available for U.S. and Canada
With your 30-day online cost-to-build estimate you can start enjoying these benefits today.
- INSTANT RESULTS: Immediate turnaround—no need to wait days for a cost report.
- RELIABLE: Gain peace of mind and confidence that comes with a reliable cost estimate for your custom home.
- INTERACTIVE: Instantly see how costs change as you vary design options and quality levels of materials!
- REDUCE RISK: Minimize potential cost overruns by becoming empowered to make smart design decisions. Get estimates that save thousands in costly errors.
- PEACE OF MIND: Take the financial guesswork out of building your dream home.
- DETAILED COSTING: Detailed, data-backed estimates with +/-120 lines of costs / options for your project.
- EDITABLE COSTS: Edit the line-item labor & material price with the “Add/Deduct” field if you want to change a cost.
Home-Cost.com’s INSTANT™ Cost-To-Build Report also provides you these added features and capabilities:
Previous Q & A
Previous Questions and Answers
A: Hello, Bedroom and master bath doors are all 3’-0” minimum. Secondary baths are 2’-4” wide. Closets are 2’-0” wide.
A: The metal building “zees” are 8” wide.
A: Its not really a “kit”, but you can get this home built by contacting any of numerous metal building suppliers. I like Sunward Steel Buildings.
A: Attic space above the secondary bedrooms.
A: It would have to be engineered for sure. Metal building company would do this. Highly recommend Sunward Steel. They’ve done this home before.
A: 8” exterior walls for the metal version. But it depends on the manufacturer you use.
A: Materials list is not included. Metal siding is standard on this plan.
A: Sure. You’ll have to use something like a metal screw to attach it.
A: The exterior walls are horizontal “Z’s” @ 4’ o.c., depending on the manufacturer. Sheetrock can be applied to these members with a little extra support in the way of furring channels or 1x2’s to provide stiffness.
A: Worldwide Steel Buildings has offered to help with this plan.
A: We recommend a couple of sources.
A: Sewer pipes go in the slab. Water pipes and electrical go above slab.
A: It will need to be engineered by the metal building supplier.
A: Yes
A: We do call out beam sizes, but the building still needs to be engineered by a metal building company. I highly recommend World Wide Steel Buildings.
A: Usually there are bolts embedded in the slab and are threaded thru holes in the bottom plate of the column then tightened down with nuts. Sometimes weld plates are used which are also embedded.
Common Questions:
A: Yes you can! Please click the "Modifications" tab above to get more information.
