a: Floor Plans: House plan drawings indicating dimensions for construction
b: Roof Plan: Drawings indicating roof slopes and unique conditions
c: Exterior Elevations: Drawings showing appearance and the types of materials used for the exterior finish
d: Building Sections: Drawings cut through important locations in the structure
e: Construction Details: Drawings showing specific construction of building elements at a large scale
f: Kitchen and bath elevations
g: Electrical Plans: Basic electrical layout (suggested locations of fixtures, switches and outlets)
h: Foundation Plan: Dimensioned drawings describing specific foundation conditions for the structure CRAWLSPACE
Plans are sent in AutoCAD 2000 format
Want to make changes?
Receive a FREE modification estimate in one of 3 ways. Our modification team is ready to help you adjust any plan to fit your needs. The ReDesign process is simple and estimates are free!
2. Print, complete and fax this PDF Form to us at 1-800-675-4916.
3. Want to talk to an expert? Call us at 913-938-8097 (Canadian customers, please call 800-361-7526) to discuss modifications.
Note: - a sketch of the changes or the website floor plan marked up to reflect changes is a great way to convey the modifications in addition to a written list.
We Work Fast!
When you submit your ReDesign request, a designer will contact you within 24 business hours with a quote.
You can have your plan redesigned in as little as 14 - 21 days!
We look forward to hearing from you!
Start today planning for tomorrow!
Cost To Build
Cost to Build Estimate
We are sorry, but an estimated cost build report is not available for this particular plan.
Previous Q & A
Previous Questions and Answers
Q:im not seeing the utility area! where is the furnace and hotwater tank?
A:Hello! It can be located under the stairs in the entry or back of the garage.
Date Posted: 19-Jul-21
Q:What is the total square footage under roof? Including finished and unfinished area?
A:2495 includes the 240sf balcony
Date Posted: 08-Jul-21
Q:Where is the space where a furnace, water heater, water softener, etc would go?
A:You can easily add those in the storage area on the lower level
Date Posted: 21-Apr-21
Q:Are the cables on the front deck decorative as I would want to eliminate them or am I going to need to a add a center post to deck to do so? Also, where does the furnace and WH go on this plan? This will be in a cold climate (in the winter months). It seems like the plan may need to be modified to add a small mechanical room on the back wall of the garage space for this purpose? Thanks, Kurt
A:Yes they are decorative cables. The furnace and water heater can be located in the garage. The original customer chose to use a mini-split system. Your garage provides plenty of room to add a mechanical room as you see fit.
Date Posted: 02-Apr-21
Q:What is the total height of the rear wall? Thinking of having rv pad on rear of house. Would need 11’ of clearance.
A:That rear wall is 18’-10” +
Date Posted: 22-Feb-21
Q:Are any of the interior walls structural?
A:Yes there are some load bearing walls The plans will indicate them
Date Posted: 01-Feb-21
Q:Does this 2-bdr plan have a loft above bdr 1, just as the 3-bdr version of this plan has?
Date Posted: 28-Nov-20
Q:I am super curious about sound- proofing between garage and living space. Would it be possible to not here power tools in garage above in main house?
A:Insulation should dampen a lot of the sound. You could double pack the insulation to help if that’s a concern
Date Posted: 25-Nov-20
Q:What is the tiny box indicating in the garage level?
A:It’s an optional sink
Date Posted: 13-Nov-20
Q:Do these plans conform to the 2018 International Residential Code?
Date Posted: 10-Nov-20
Q:Can I make modifications to this plan?
A:Yes you can! Please click the "Modifications" tab above to get more information.
Q:What is the estimated price to build this plan?
A:The national average for a house is running right at $125.00 per SF. You can get more detailed information by clicking the Cost-To-Build tab above. Sorry, but we cannot give cost estimates for garage, multifamily or project plans.
