Our working drawings include the following..
We use AutoCAD to produce our working drawings. This allows us to be 100% accurate on our dimensions as well as coordinate all drawings with the highest level of precision. Below are examples of what comes in each working drawing set...
Floor Plans -
For each level we include... a 1/4"=1'-0" scale floor plan indicating frame walls and masonry with dimensions, notes, door and window sizes, room names and floor finishes, cabinet, shelving, fixture locations and notes, ceiling conditions, electrical/lighting fixtures and switches.
Exterior Elevations -
We include... Front Elevation at 1/4"=1'-0", side and rear elevations at 1/8"=1'-0", plate heights, roof overhangs, material/surface notes, window heights, roof pitches, material hatching for clarity, floor to floor dimensions and any other detail we feel is necessary to explain the construction.
Cabinet elevations at 3/8"=1'-0", showing cabinets, appliance locations, plumbing fixtures, shelving, counter/backsplash surface, cabinet material and finish, niche details and any other special situation that cannot be understood from the plan view. Building Sections are included only when there is no other way to indicate the spatial characteristics of the home. This information is quite often indicated well enough on the elevations and plans.
Foundation Plans -
We offer a choice of three types of foundations, full basement, crawlspace, and slab foundations. Each comes fully dimensioned, and noted indicating wall composition and thickness, construction detail references to our detail page, beam, pier and column locations and sizes, stair locations for basements, reinforcing steel sizes and step downs in monolithic slabs and ventilation grilles for crawlspaces.
Framing Plans -
For each level we include... a 1/8"=1'-0" scale plan indicating rafter, ceiling and floor joists locations, sizes and spacing as well as lumber grade specified, additional bracing and blocking.
For each foundation type we include... 3/4"=1'-0" scale details indicating material composition, size and critical dimensions for construction of the primary foundation.
Want to make changes?
Plan modification is a way of turning a stock plan into your unique custom plan. It's still just a small fraction of the price you would pay to create a home plan from scratch. Simply contact the modification department at...
Phone: 866-465-5866 - Talk to a live person that can give you and FREE modification estimate over the phone!
Fax: 651-602-5050 - Make sure to include a cover sheet with your contact info. Make attention to the COOLhouseplans.com Modification Department. Email Us Please Include your telephone number, plan number, foundation type, state you are building in and a specific list of changes.
...and you will receive a FREE, no obligation, modification estimate to get exactly the home plan you've been dreaming of.
Cost To Build
No Risk Offer: Order the QUICK-Cost-To-Build now and when you do decide to order any house plan, $19.95 will be deducted from your order! *
Get more accurate results, quicker! No need to wait for a reliable cost.
Get a detailed cost report for your home plan with over 70 lines of summarized cost information in under 5 minutes!
Cost report for your zip code. (the zip code can be changed after you receive the online report)
Estimate 1, 1-1/2 or 2 story home plans. **
Interactive! Instantly see the costs change as you vary quality levels Economy, Standard, Premium and structure such as slab, basement and crawlspace.
QUICK Cost-To-Build estimates have the following assumptions:
QUICK Cost-To-Build estimates are available for single family, stick-built, detached, 1 story, 1.5 story and 2 story home plans with attached or detached garages, pitched roofs on flat to gently sloping sites.
QUICK Cost-To-Build estimates are not available for specialty plans and construction such as garage / apartment, townhouse, multi-family, hillside, flat roof, concrete walls, log cabin, home additions, and other designs inconsistent with the assumptions outlined in Item 1 above.
User is able to select and have costs instantly calculate for slab on grade, crawlspace or full basement options.
User is able to select and have costs instantly calculate different quality levels of construction including Economy, Standard, Premium. View Quality Level Assumptions.
Estimate will dynamically adjust costs based on the home plan's finished square feet, porch, garage and bathrooms.
Estimate will dynamically adjust costs based on unique zip code for project location.
All home plans are based on the following design assumptions: 8 foot basement ceiling height, 9 foot first floor ceiling height, 8 foot second floor ceiling height (if used), gable roof; 2 dormers, average roof pitch is 12:12, 1 to 2 covered porches, porch construction on foundations.
Summarized cost report will provide approximately 70 lines of cost detail within the following home construction categories: Site Work, Foundations, Basement (if used), Exterior Shell, Special Spaces (Kitchen, Bathrooms, etc), Interior Construction, Elevators, Plumbing, Heating / AC, Electrical Systems, Appliances, Contractor Markup. View a LIVE Sample Cost Report.
QUICK Cost-To-Build generates estimates only. It is highly recommend that one employs a local builder in order to get a more accurate construction cost.
All costs are "installed costs" including material, labor and sales tax.
* Limit one $19.95 credit per complete plan package order.
** Available for U.S. only.
Previous Q & A
Previous Questions and Answers
Q:What type of exterior shingle is used please?
A:We call for cedar shakes. I’d recommend a Hardi-Board or Royal Building Products shake though in hind sight. Much lower maintenance.
Date Posted: 26-Mar-19
Q:Do the stated width and depths on a this plan include the whole structure footprint? I need to submit dimensions to get a perc test done? Any insight on that would help. Tx
A:Yes. Our measurement is to the outermost edges of the foundation.
Date Posted: 09-Feb-17
Q:do you have a finished walk out basement plan with rooms named for this house
A:We have a walk-out basement which is currently just wide open space and structural columns.
Date Posted: 09-Jan-17
Q:Is the second floor included in total living space?
A:No, it is another 800 SF.
Date Posted: 19-Sep-16
Q:Can 4 beds and 2 baths fit upstairs? Any additional common space in addition to that? Would that have major impact on the front elevation?
A:Yes, you could get 4 brs and 2 baths from that plan with no changes to the front elevation.
Date Posted: 22-Aug-16
Q:We are considering this plan for an immediate build on a sloped lot. We would like the Walk out basement portion of the plan. Our question is, if we don't need to are over the garage, what can we do with all of that space?
A:It would just be attic then.
Date Posted: 03-Aug-16
Q:Do you have any representations or elevations of a walk out basement option on the rear? I'm curious what it would look like and what would be done with the Lanai and BBQ porch if a walk out basement is implemented.
A:Have attached a sketch of a similar plan with the walk-out that has the same Lanai and BBQ. It just becomes a raised deck.
Q:Do you have a walkout basement plan for this house
A:Yes. Same price, just specify walk-out basement when ordering.
Date Posted: 12-Oct-15
Q:what part of the country are these plans drawn up for
A:Originally for Texas.
Date Posted: 28-Apr-15
Q:Can you please tell me if the columns and such around the dining room space are structural? Thank you.
A:We use them as structural but they could be removed by using larger ceiling beams.
Date Posted: 08-Apr-15
Q:Can you tell me the width and depth of the house including the garage?
A:88’-8” wide x 84’-10” deep
Date Posted: 20-Oct-14
Q:can you remove the fireplace from the Plan? I don't need it in the Philippines.
A:Of course. Your builder can handle a change like that in the field pretty easily.
Date Posted: 13-May-14
Q:I love this plan but where is the mechanical room for your hot water tank, furnace, and air exchanger if u don't build a basement? For cold weather climate (such as canada) these can't be located in an unheated garage.
A:Most cold weather foundations have to be deep enough for the frost line to make doing a basement logical.
Date Posted: 04-Feb-14
Q:I noticed on the specs that this plan has vaulted ceilings. Which rooms have the vaulted ceilings? I love this plan, but really want vaulted ceilings in the family room and possibly on the lanai. Also is there an option to build out only a couple hundred square feet upstairs as opposed to the entire area?
A:There's is actually about 800 sf designed upstairs, but it could be expanded. Ceilings are easy to modify in the field or on paper.
Date Posted: 04-Feb-14
Q:I'm thinking about ordering plans for this house and it would be a crawlspace design.1) can they be ordered with beam and floor jouced structure? 2) If plans cannot be ordered with beam and floor jouce, do you have a relationship with an engineering firm in WA? 3) are all cantaleaver ceilings spelled out?
A:We do have a crawlspace foundation which is pier and beam framing. The ceiling treatments are all noted on the plan.
Date Posted: 18-Dec-13
Q:Do you have any images of the interior?
A:No, but they are similar to Plan 65862.
Date Posted: 18-Nov-13
Q:Need to know if the roof height will allow for bathroom in the upstairs bathroom.
A:Yes, plenty of room.
Date Posted: 15-Jul-13
Q:can you tell me if any attic space is big enough to floor a large section and walk in?
A:There is already 900 (+/-) SF of Bonus area over the garage and master bath area, but yes, there is plenty of additional attic area to create additional walk-in space.
Date Posted: 09-Apr-13
do your plans include mechanical and electrical drawings?
Also do they meet Canadian and Ontario building code standards?
A:We do not include mechanical as it is impossible to figure prior to knowing the orientation of the home. We do include electrical (schematic) showing light fixtures, outlet, switches and their locations, how they are connected. The only thing we do not provide is circuiting and wire sizes.
We adhere to the IRC, for compliance with Canadian codes I would have to defer to a local authority on that.
Date Posted: 06-Jan-11
Q:We would like to know the specifics of the exterior? Is is stone, wood, etc. Also, are there any other choices on the exterior that you can send? i.e. all brick, brick & stone etc. We are very interested in this floor plan design, but are concerned about exterior maintenance. We would like a maintenance free exterior. Please advise any choices or suggestions. Thanks, Randy & Linda Harris, North Carolina.
A:Exterior materials are stone and a cedar shake material that could be a hardi-board product that is very low maintenance. The trusses in the gable could also be hardi-board, but that might take some thought as to how to achieve it. I would still recommend a high quality stain in the trusses.
Date Posted: 14-Dec-10
Q:Is the exterior material...a combination of stone and brick? Is the faciia board and materials on the dormers and decorative trom wood? Can it be of a maintenance free material?
A:The exterior is a combination of stone and cedar shakes(or a hardi-board substitute). I recommend the hardi-products line for any and all exposed wood materials - fascia, soffits, trim and siding.
Date Posted: 13-Dec-10
Q:Can I make modifications to this plan?
A:Yes you can! Please click the "Modifications" tab above to get more information.
Q:What is the estimated price to build this plan?
A:The national average for a house is running right at $125.00 per SF. You can get more detailed information by clicking the Cost-To-Build tab above. Sorry, but we cannot give cost estimates for garage, multifamily or project plans.
